Biotecnica BT 3000 Plus Chemistry Analyzer

In Stock

This combination does not exist.

Request A Quote

Get your quote in 90 minutes.
Trade in your older analyzers to recover budget.
Bundle equipment, reagents, & consumables into one cost-saving order.
Enlist our local service tech to keep uptime high.
Lower your cost per test.

Product Code: BT-3000

WHY CHOOSE MYCO INSTRUMENTATION?
See Why in 2 mins.

The experience reached with the analyser BT3000 Plus, one of the most famous and diffused analysers for clinical chemistry in the world, have produced his/her logic evolution:

The point of reference for the future in the modern laboratory of clinical analysis. The Know how thirty-year of the Biotecnica Instruments SpA matured in the sector, has allowed the realization of this new analyser perfect synthesis of technology, performances and design. The theme proposed to our planners has been that to realize a new tool, that in the raccoglierel'esperienza of the preceding series of analysers, it maintained the formulation of it bringing all the improvements and innovations that technology allows. List of some special characteristics and technical performances that it makes of this analyser an assembled of technology and reliability, been born by the experience of a society Leader in the world:

12 microcontroller of last generation that manage, coordinated by the central unity teninspectors of last generation that manage, coordinated by the central unity, ten different microsystems for a great speed of elaboration and availability of resources for the central unity.
Connection among the processors with technical dual wire for a great protection of the circuits from the external troubles..
New feeder with technology PFC (Power Factor Correction) to tall performances and energy saving..
DVD multimedia capability
WINDOWS 7 32 bit interface software

TECHNICAL SPECIFICATIONS
Throughput	Up to 300 Chem. Tests/hr + up to 190 ISE Tests/hr
ISE Module on board	Yes: Na, K, Cl, CO2
Number of reagents	80 Total - (40 for or 80ml + 40 for 10ml or 20ml)
Refrigerated Reagent Bay	Yes
Reaction volume	From 280 to 700 µl
Sample volume	From 1 to 100 µl
Reading cuvettes	34 non-disposable optical glass
Sampling Arm	2 for Serum and Reagents
Number of position	78 Total - 52 Samples - 26 Standards and Control
Test Modes	Random Access, Batch, STAT
Test Directory	Up to 500
Temperature control	Peltier System OFF/30/32/37°C (±0,2°C)
Vacuum Pump	External
Photometer	Solid state 10 channel + Reference channel
Photometer Accuracy	± 1% (0-2 O.D.), + 2,5% (2-3 O.D.)
Photometer Sensitivity	± 0,001 Abs
Diluter	2 - Long life ceramic 470 µl
Diluter Accuracy	± 0,1% f.s.
Diluter Sensitivity	± 1 µl
Bar Code	2: Reagent and Serum
Internal Computer	CPU Atom 1.8 GHz
Peripheral Devices	DVD ROM, HD>40 Gb
Monitor	Color LCD 12"
Touch-screen	Yes: Glass Protected resistive kind
Keyboard	U.S.A. Standard
Mouse	Yes
Software	Windows® 7 32 bit
Process electronic	12 Microcontrollers I² CBUS Protocol
Interface	RS232, Bidirectional + USB + LAN + VGA
Built in QC Program	Yes: 3 Levels known, 3 Levels Unknown
Maintenance	Software assisted
Power Supply	100/240 Volt, 50-60Hz, 1000 Watts, PFC
Environmental temperature	18 - 32°C (64.4-89.6°F)
Relative humidity	10 - 85% (not condensing)
Dimension	Height - 27", Width - 40", Depth - 23"
Weight	210 lb (95 Kg.)
Windows 2000®, Intel Pentium® and Cubitainer® are registered of Microsoft Corporation, Intel and Emergency Resources. IBM is registered trademark of the International Business Machine.
Features may change without notice
