Sysmex XS 1000i

Sysmex XS 1000i

This system offers the below features:

Models

• XS-1000i – closed tube sampling
• XS-1000i – with auto sampler (closed tube)

XS-1000i system includes

• XS-1000i analyzer 12.6” W x 15.9” H x 16.3” D; 52.8 lbs.
• All in one computer/monitor
• Bar code reader
• Laser printer
• Auto sampler (optional) 16.7” W x 15.9” H x 24.2” D; 74.8 lbs.

XS-1000i Specifications

• Operating System – Windows® XP
• Sample Storage – 10,000 records with scattergrams
• Ideal lab testing volumes – up to 60 CBC+DIFF/24hr
• Discrete test options – CBC or CBC+DIFF
• Common reagents and e-CHECK control as XE and XT-Series

Measurement Principles

• RBC/PLT – Sheath flow direct current as on XE and XT-Series
• WBC – Semiconductor laser flow cytometry
• HGB – Colorimetric method (SLS)

Testing Parameters

• CBC and S-part differential
• 21 Parameters: WBC, RBC, HGB, HCT, MCV,
• MCH, MCHC, RDW-SD, RDW-CV, PLT, MPV,
• NEUT%, NEUT#, LYMPH%, LYMPH#, MONO%,
• MONO#, EOS%, EOS#, BASO%, BASO#

Throughput

• Single sample mode – 60 samples/hr
• Auto sampler mode – 53 sampler/hr

Quality Control

• 20 files
• L-J or X-barM measurement
• Common QC material to XE and XT-Series

Linearity Specifications

• WBC 0 – 400 x 103 μ/L
• RBC 0 – 8.00 x 106 μ/L
• HGB 0 – 25.0 g/dl
• HCT 0 – 60%
• PLT 0 – 5,000 x 103 μ/L

• Weight: 53 Lbs.
• Dimensions: 13(W) x 16(H) x 16(D) inches
• Auto Sampler: 75 Lbs.
